Catalyst Hardware RF Systems

Turn-key RF front-ends/tuners available for use in 5G Communications, Radar, ELINT, ESM, and EW applications.

Starting at
$5,000
CR2
"Coin" form-factor system featuring 2 RF channels optimized for space-constrained payloads. Stackable design allows for ulimate configuration.
Configure SYSTEMRequest A QUOTE
  • Size: 24mm Diameter, configurable height
  • Operating Frequency: 0.02-20GHz
  • Maximum input: 20dBm
  • Gain: 0dB (typical)
  • Noise Figure: <9dB (typical)
  • OIP3: 15dBm (typical)
  • Prog. Atten: 32dB @ 0.5dB/step
  • LO Tune time: 20us
  • External Reference (Optional): 40-200MHz
  • RF Channels: 2
  • IF Channels: 2
  • SFDR: 60dBc (typical)
  • Channel Isolation: 35dB (typical)
  • Tuneable RF Filters: DC-20GHz
  • Digital Control: GPIO + SPI
  • Weight: 28g
  • Power: 9W (12V rail)
Learn more
Starting at
$50,000
VPX4
Newest SPRC4 architecture design in a 3U form Factor. Leverage the highest-performance of the SPRC4 with the open SOSA/VPX standards.
Configure SYSTEMREQUEST A QUOTE
  • Size: 1" Pitch 3U VPX
  • Operating Frequency: 0.02-20GHz
  • Maximum input: 50dBm
  • Gain: 25dB (typical)
  • Noise Figure: <9dB (typical)
  • OIP3: 20dBm (typical)
  • Prog. Atten: 32dB @ 0.5dB/step
  • LO Tune time: 20us
  • External Reference (Optional): 40-200MHz
  • RF Channels: 4
  • IF Channels: 4
  • SFDR: 65dBc (typical)
  • Channel Isolation: 50dB (typical)
  • Tuneable RF Filters: DC-20GHz
  • Digital Control: 1GbE (1000Base-X, 1000Base-T), USB
  • Weight: 680g
  • Power: 30W (12V rail)
